High precision wide power supply high output drive low noise reference
2023-03-08
The LT6654 is a family of small precision voltage references that offers high accuracy, low noise, low drift, low dropout and low power. The LT6654 operates from voltages up to 36V and is fully specified from –55°C to 125°C. A buffered output ensures ±10mA of output drive with low output impedance and precise load regulation. These features, in combination, make the LT6654 ideal for portable equipment, industrial sensing and control, and automotive applications.
High performance, high reliability CMOS technology manufacturing
2023-03-08
IDT6116SA/LA is a 16384-bit high-speed static RAM with a structure of 2K x 8. It is packaged with 24-pin 600 and 300 mil plastic or ceramic DIP, 24-pin gull-wing SOIC and 24-pin j-bend SOJ, providing high board-level packaging density. Military grade products meet the latest version of MIL-STD-883, Grade B, which makes them very suitable for military temperature applications requiring the highest performance and reliability.
Maxim Integrated introduces the dual channel buffer
2023-03-08
The MAX4951BE dual-channel buffer is ideal for re-driving serial ATA (SATA) I, SATA II, and SATA III signals, and has high electrostatic discharge (ESD) Q8kV Mannequin (HBM) protection. The MAX4951BE is powered by a single +3.3V(typical) power supply and can flow through traces in a small, 4mm x 4mm TQFN package for easy layout. The operating temperature range of the equipment is 0NC to +70NC.
Texas Instruments railroad automatic distribution switch
2023-03-08
The TPS201xA family of power distribution switches is intended for applications where heavy capacitive loads and short circuits are likely to be encountered. These devices are 50-mΩ N-channel MOSFET high-side power switches. The switch is controlled by a logic enable compatible with 5-V logic and 3-V logic. Gate drive is provided by an internal charge pump designed to control the power-switch rise times and fall times to minimize current surges during switching. The charge pump requires no external components and allows operation from supplies as low as 2.7 V.
High efficiency, high voltage 100mA synchronous step-down converter
2023-03-07
The LTC3631 is a high voltage, high efficiency step-down DC/DC converter with internal high side and synchronous power switches that draws only 12μA typical DC supply current at no load while maintaining output voltage regulation.
PWM controller with 1A drive current capability
2023-03-07
The MIC38HC4x family are fixed frequency current-mode PWM controllers with 1A drive current capability. Micrel’s BiCMOS devices are pin-compatible with 384x bipolar devices. Their high output drive, with fast rise and fall times, combined with low startup current make it an ideal PWM controller where high efficiency is required
Step-down, PWM control or PWM/PFM toggable switch regulator controller
2023-03-07
The S-8520/8521 Series is a CMOS step-down switching regulator-controller with PWM control (S-8520 Series) and PWM / PFM switching control (S-8521 Series). The S-8520/8521 Series has a reference voltage source, an oscillation circuit, an error amplifier, and other components
Texas Instruments High speed synchronous step-down regulator controller
2023-03-07
The LM2743 is a high-speed synchronous buck regulator controller with an accurate feedback voltage accuracy of ±2%. It can provide simple down conversion to output voltages as low as 0.6 V. Though the control sections of the IC are rated for 3 V to 6 V, the driver sections are designed to accept input supply rails as high as 16 V. The use of adaptive non-overlapping MOSFET gate drivers helps avoid potential shoot-through problems while maintaining high efficiency.
Integrated power hybrid integrated circuits for electric motor drives of household appliances
2023-03-06
IRAM336-025SB is a multi-chip hybrid IC for low power electrical motor control applications such as fans, pumps and refrigerator compressors. A compact Single in line (SIP-S) package minimizes PCB space. Several built-in protection features such as temperature feedback, shot prevention, undervoltage locking and shutdown input make this a very powerful solution.
2.5-A QFN Encapsulates 7V-50V input power modules
2023-03-06
The LMZ35003 Power module is an easy-to-use integrated power solution that integrates 2.5a DC/DC converters with shielded inductors and passivity into a low-profile QFN package. And provides the flexibility and function set of discrete load point design, ideal for powering a wide range of ics and systems. Advanced packaging technology provides a powerful and reliable power solution compatible with standard QFN installation and testing techniques.
Digital polyphase memory/mobile controller
2023-03-03
The IR3596 is a flexible single-loop digital polyphase step-down controller that can be configured as a 1, 2 or 3 phase system when combined with an IR Dual 6x8mm IR3548 or IR355x power level. Power consumption is minimized while maintaining full digital capability and flexibility. Digital nonlinear transient control allows low frequency operations to achieve maximum efficiency while providing minimal all-ceramic output capacitance solutions.
High efficiency synchronous boost converter is disconnected from 4.2A switch and output
2023-03-03
The ISL91117 is a highly integrated boost switch regulator for battery powered applications. The device provides power solutions for products using two - or three-cell alkaline, NiCd or NiMH, or single-cell lithium-ion or lithium polymer batteries. The size of the power solution is minimized with a 2.34mm x 1.72mm WLCSP and a 2.6MHz switching frequency, which allows the use of tiny, low-size inductors and ceramic capacitors to minimize the size of the solution.
Programmable touch screen controller with stereo audio codec
2023-03-03
TSC2302 is a highly integrated pda analog interface circuit. Supplied with 48-pin QFN. It contains a full 12-bit a /Dresistive Touch Screen converter (ADC) including driver, touch pressure measurement function, and 8-bit D/ a converter (DAC) output for LCD contrast control.
Double ideal diode and single hot swap controller
2023-03-03
The LTC4227 provides ideal diode or hot swap functionality for both power tracks by controlling an external nchannelmosfet. As an ideal diode, the MOSFETs replace two high-power Schottky diodes and associated heat sinks, saving power and board area. A hot-swap control MOSFET allows a plate to be securely inserted and operated from the active backplane by limiting the influx current. The power output also protects against short-circuit failures with fast-acting current limiting and internal timing circuit breakers
Renesas Synchronous Rectified MOSFET Driver
2023-03-02
ISL6605 is a high-frequency MOSFET driver, which optimizes the topology of two n-channel power MOSFETs in synchronous rectification buck converter. The driver is combined with Intersil HIP63xx or ISL65xx polyphase step-down PWM controller to form a complete single-stage core voltage regulator solution with high efficiency at high switching frequency, suitable for advanced microprocessors.
Low cost, high isolation voltage, unregulated, single and double output DC/DC converters
2023-03-02
The PWR13XXC Series offers a broad line of low-cost, high-isolation voltage, unregulated, single and dual output DC/DC converters in a 24-pin DIP package. These small converters offer a 4000V isolation rating in a 1.25" x 0.8" package area. The dielectric withstand characteristics of each converter is tested in production to ensure barrier integrity.
Toshiba introduces new DC brushless motor grid drive IC
2023-03-02
TB9083FTG is a front-drive IC for brushless motors in vehicles. In addition to the three-phase predriver, it has a safety relay predriver built in. It also includes charge pump, motor current detection circuit, oscillator circuit and SPI communication circuit. It has a variety of error detection capabilities. Trigger thresholds, response actions, and other Settings are modified by SPI. The TB9083FTG is also equipped with ABIST/LBIST for testing and evaluation of error detection capabilities
High performance W-CDMA power amplifier module
2023-03-02
The ACPM-7881 is a high performance W-CDMA power amplifier module in a 4x4x1.1mm package. Using surface mount RF package design, with high cost and size competitiveness
