Key on-off mode PFC controller
2023-02-12
The FAN7930C is an active power factor correction (PFC) controller for boost PFC applications that operate in critical conduction mode (CRM). It uses a voltage−mode PWM that compares an internal ramp signal with the error amplifier output to generate a MOSFET turn−off signal. Because the voltage−mode CRM PFC controller does not need rectified AC line voltage information, it saves the power loss of an input voltage−sensing network necessary for a current−mode CRM PFC controller
10-bit digital temperature sensor (AD7416) and 4 channel /1 channel adc
2023-02-12
The AD7417 and AD7418 are 10-bit, 4-channel and single-channel ADCs with an on-chip temperature sensor that can operate from a single 2.7 V to 5.5 V power supply. The devices contain a 15 μs successive approximation converter, a 5-channel multiplexer, a temperature sensor, a clock oscillator, a track-and-hold, and a reference (2.5 V). The AD7416 is a temperature-monitoring only device in an 8-lead package.
5-bit programmable synchronous step-down controller Integrated circuit with triple ldo controller
2023-02-11
The IRU3027 controller IC is specifically designed to meet VRM 9.0 specification for next generation microprocessor applications requiring multiple on-board regulators. The IRU3027 provides a single chip controller IC for the Vcore, three LDO controllers, one with an automatic select pin that connects to the Type Detect pin of the AGP slot for the AGP VDDQ supply, one for GTL+ and the other for the 1.8V chip set regulator as required for the next generation PC applications.
300mA low voltage (LDO) linear regulator
2023-02-11
The AP130 is a 300mA, fixed output voltage, low dropout linear regulator. The device includes pass element, error amplifier, band-gap, current-limit and thermal shutdown circuitry.
500mA, low noise, LDO micro power regulator
2023-02-11
The LT1763 series are micropower, low noise, low dropout regulators. The devices are capable of supplying 500mA of output current with a dropout voltage of 300mV. Designed for use in battery-powered systems, the low 30µA quiescent current makes them an ideal choice. Quiescent current is well controlled; it does not rise in dropout as it does with many other regulators.
The voltage converter of the Microchip 100mA charging pump is shut down
2023-02-11
The TC1121 is a charge pump converter with 100mA output current capability. It converts a 2.4V to 5.5V input to a corresponding negative output voltage. As with all charge pump converters, the TC1121 uses no inductors saving cost, size and EMI
Single channel, high current, low voltage, protected distribution switch
2023-02-11
The MIC2042 and MIC2043 are high-side MOSFET switches optimized for general purpose power distribution applications which require circuit protection. The devices switch up to 5.5V and as low as 0.8V while offering both programmable current limiting and thermal shutdown to protect the device and the load.
8 character, microprocessor compatible, LED display decoder driver
2023-02-11
The ICM7243 is an 8-character, alphanumeric display driver and controller which provides all the circuitry required to interface a microprocessor or digital system to a 14-segment or 16-segment display. It is primarily intended for use in microprocessor systems, where it minimizes hardware and software overhead. Incorporated on-chip are a 64-character ASClI decoder, 8x6 memory, high power character and segment drivers, and the multiplex scan circuitry
Microchip 4.0-A dual high-speed power MOSFET driver enabled
2023-02-11
The MCP14E3/MCP14E4/MCP14E5 device is A 4.0-A buffer /MOSFET driver family. Double inverting, double non inverting, and complementary outputs are standard logical options. Capable of operating on a single power supply from 4.5V to 18V, and can easily charge and discharge a 2200 pF gate capacitor in less than 15ns(typical)
ON Semiconductor 14 bit binary counter and oscillator
2023-02-11
The MC14060B is a 14−stage binary ripple counter with an on−chip oscillator buffer. The oscillator configuration allows design of either RC or crystal oscillator circuits. Also included on the chip is a reset function which places all outputs into the zero state and disables the oscillator. A negative transition on Clock will advance the counter to the next state. Schmitt trigger action on the input line permits very slow input rise and fall times. Applications include time delay circuits, counter controls, and frequency dividing circuits
Texas Instruments precision integrated circuit temperature sensor
2023-02-10
The LM60 device is a precision integrated-circuit temperature sensor that can sense a −40°C to +125°C temperature range while operating from a single 2.7-V supply. The output voltage of the device is linearly proportional to Celsius (Centigrade) temperature (6.25 mV/°C) and has a DC offset of 424 mV. The offset allows reading negative temperatures without the need for a negative supply. The nominal output voltage of the device ranges from 174 mV to 1205 mV for a −40°C to +125°C temperature range.
12-bit, 3Msps, sampling A/D converter
2023-02-10
The LTC1412 is a 12-bit, 3Msps, sampling A/D converter. This high performance device includes a high dynamic range sample-and-hold and a precision reference. Operating from ±5V supplies it draws only 150mW.
8/10/12 bit dual-voltage output digital-to-analog converter with built-in VREF and SPI interfaces
2023-02-10
The MCP4802/4812/4822 devices are dual 8-bit, 10-bit and 12-bit buffered voltage output Digital-to-Analog Converters (DACs), respectively. The devices operate from a single 2.7V to 5.5V supply with SPI compatible Serial Peripheral Interface.
Analog Devices 8 bit, high speed, multiplicative D/A converter
2023-02-10
The DAC08 series of 8-bit monolithic digital-to-analog converters provide very high speed performance coupled with low cost and outstanding applications flexibility.
Texas Instruments 3.5 a step-down switch regulator
2023-02-10
The L4973 is a step down monolithic power switching regulator delivering 3.5 A at fixed voltages of 3.3 V or 5.1 V and using a simple external divider output adjustable voltage up to 50V. Realized in BCD mixed technology, the device uses an internal power D-MOS transistor (with a typical RDS(on) of 0.15 Ω) to obtain very high efficiency and very fast switching times. Switching frequency up to 300 kHz are achievable (the maximum power dissipation of the packages must be observed)
Exar Corporation provides an 800mA low voltage step-down regulator
2023-02-10
The SPX1117 is a low power positive-voltage regulator designed to satisfy moderate power requirements with a cost effective, small footprint solution.
Texas Instruments low IQ, low dropout regulator
2023-02-09
TLV702 series Low voltage drop (LDO) linear regulators are low static current devices with excellent line and load transient performance. An active pull-down circuit is provided for rapid discharge output. The TLV702 series LDO linear regulators are available in SOT23-5 and 1.5mm × 1.5mm WSON-6 packages.
With a functional power converter 150 kHz 2A step-down regulator
2023-02-09
The LM2593HV series of regulators are monolithic integrated circuits that provide all the active functions for a step-down (buck) switching regulator, capable of driving a 2A load with excellent line and load regulation. These devices are available in fixed output voltages of 3.3V, 5V, and an adjustable output version
